`polygon`

draws the polygons whose vertices are
given in `x`

and `y`

.

```
polygon(x, y = NULL, density = NULL, angle = 45,
border = NULL, col = NA, lty = par("lty"),
…, fillOddEven = FALSE)
```

x, y

vectors containing the coordinates of the vertices of the polygon.

density

the density of shading lines, in lines per inch. The
default value of `NULL`

means that no shading lines are drawn.
A zero value of `density`

means no shading nor filling whereas
negative values and `NA`

suppress shading (and so allow
color filling).

angle

the slope of shading lines, given as an angle in degrees (counter-clockwise).

col

the color for filling the polygon. The default,
`NA`

, is to leave polygons unfilled, unless `density`

is
specified. (For back-compatibility, `NULL`

is equivalent to
`NA`

.) If `density`

is specified with a positive value
this gives the color of the shading lines.

border

the color to draw the border. The default, `NULL`

,
means to use `par("fg")`

. Use `border = NA`

to
omit borders.

For compatibility with S, `border`

can also be logical, in
which case `FALSE`

is equivalent to `NA`

(borders omitted)
and `TRUE`

is equivalent to `NULL`

(use the foreground colour),

lty

the line type to be used, as in `par`

.

…

graphical parameters such as `xpd`

, `lend`

,
`ljoin`

and `lmitre`

can be given as arguments.

fillOddEven

logical controlling the polygon shading mode: see
below for details. Default `FALSE`

.

Self-intersecting polygons may be filled using either the
“odd-even” or “non-zero” rule. These fill a region if
the polygon border encircles it an odd or non-zero number of times,
respectively. Shading lines are handled internally by R according
to the `fillOddEven`

argument, but device-based solid fills
depend on the graphics device. The `windows`

, `pdf`

and `postscript`

devices have their own `fillOddEven`

argument to control this.

The coordinates can be passed in a plotting structure
(a list with `x`

and `y`

components), a two-column matrix,
…. See `xy.coords`

.

It is assumed that the polygon is to be closed by joining the last point to the first point.

The coordinates can contain missing values. The behaviour is similar
to that of `lines`

, except that instead of breaking a line
into several lines, `NA`

values break the polygon into several
complete polygons (including closing the last point to the first
point). See the examples below.

When multiple polygons are produced, the values of `density`

,
`angle`

, `col`

, `border`

, and `lty`

are recycled
in the usual manner.

Shading of polygons is only implemented for linear plots: if either axis is on log scale then shading is omitted, with a warning.

Becker, R. A., Chambers, J. M. and Wilks, A. R. (1988)
*The New S Language*.
Wadsworth & Brooks/Cole.

Murrell, P. (2005) *R Graphics*. Chapman & Hall/CRC Press.

`segments`

for even more flexibility, `lines`

,
`rect`

, `box`

, `abline`

.

`par`

for how to specify colors.

# NOT RUN { x <- c(1:9, 8:1) y <- c(1, 2*(5:3), 2, -1, 17, 9, 8, 2:9) op <- par(mfcol = c(3, 1)) for(xpd in c(FALSE, TRUE, NA)) { plot(1:10, main = paste("xpd =", xpd)) box("figure", col = "pink", lwd = 3) polygon(x, y, xpd = xpd, col = "orange", lty = 2, lwd = 2, border = "red") } par(op) n <- 100 xx <- c(0:n, n:0) yy <- c(c(0, cumsum(stats::rnorm(n))), rev(c(0, cumsum(stats::rnorm(n))))) plot (xx, yy, type = "n", xlab = "Time", ylab = "Distance") polygon(xx, yy, col = "gray", border = "red") title("Distance Between Brownian Motions") # Multiple polygons from NA values # and recycling of col, border, and lty op <- par(mfrow = c(2, 1)) plot(c(1, 9), 1:2, type = "n") polygon(1:9, c(2,1,2,1,1,2,1,2,1), col = c("red", "blue"), border = c("green", "yellow"), lwd = 3, lty = c("dashed", "solid")) plot(c(1, 9), 1:2, type = "n") polygon(1:9, c(2,1,2,1,NA,2,1,2,1), col = c("red", "blue"), border = c("green", "yellow"), lwd = 3, lty = c("dashed", "solid")) par(op) # Line-shaded polygons plot(c(1, 9), 1:2, type = "n") polygon(1:9, c(2,1,2,1,NA,2,1,2,1), density = c(10, 20), angle = c(-45, 45)) # }
